COM Interop with .NET Core 3.x and .NET 5.0

I previously wrote about COM Interop with .NET Core 1.0 and .NET Core 2.0. I haven’t had a chance to write it about it since, so this discusses both .NET Core 3.x and .NET 5.0.  If it wasn’t obvious from the previous articles, this is about calling COM components from .NET.  I believe work was done using COM interop in the other direction (calling .NET from COM components), but it is not discussed here. If you need to call .NET from Visual FoxPro, wwDotNetBridge is much simpler than standard COM Interop and highly recommended.

.NET Core 3.x

.NET Core 3.0 was a big release.  Unlike ASP.NET Core 2.0, ASP.NET Core 3.0 removed the option to run on .NET Full Framework 4.x.  It only runs on .NET Core, meaning you can no longer fall back to 4.x for COM Interop support.  WinForms and WPF desktop applications were also brought into the Core fold for the first time, and some of those apps might rely on COM Interop.

Some progress was made in 3.0, but the overall COM Interop story is the same as .NET Core 2.0.  That is, COM Interop works, but late binding using the C# dynamic keyword still doesn’t function.

dynamic excel = Activator.CreateInstance(Type.GetTypeFromProgID("Excel.Application", true));
excel.Visible = true;
Console.WriteLine("Press Enter to close Excel.");
Console.ReadLine();
excel.Quit();

As with .NET Core 2.0, the above code will function in .NET Framework 4.x, but in .NET Core 3.x, an exception occurs:

‘System.__ComObject’ does not contain a definition for ‘Visible’

Microsoft had planned to bring full support for the dynamic keyword to .NET Core 3.0, but the job proved to be too large, so it was deferred. However, there are a couple of improvements.

In .NET Core 2.0, you had to jump through hoops to create an interop assembly for COM components.  In .NET 3.x projects with Visual Studio 2019, you can simply right-click on the project and select “Add COM Reference”.

In addition, some folks put together a workaround using a DynamicObject wrapper to access properties/methods on COM objects using the dynamic keyword, so you don’t have to use ugly reflection calls.  This may not work in every scenario, but you may find it meets your needs on .NET Core 3.x.

.NET 5.0

.NET 5.0 was just launched at .NET Conf on November 10, 2020. It represents the reunification of .NET Core and .NET Full Framework, hence the dropping of “Core” in the product name.  .NET 4.x remains a part of Windows and will continue to be supported indefinitely.  Some things are not coming over to .NET 5, such as Web Forms, WCF, and WWF… at least not by Microsoft. There are open-source projects to port WCF and WWF.  But what about COM Interop?  In my testing, it just works.  Indeed, Microsoft finished the work to support using the dynamic keyword with COM objects.  There’s not much more to say than that.  If incomplete COM Interop support has been keeping you on .NET Full Framework 4.x, now may be the time to take a look at .NET 5.0.

ParallelFox 1.3 Released

The last release of ParallelFox was over 8 years ago in January 2012.  Also, 3 years have somehow elapsed since CodePlex was shut down and VFPX moved to GitHub. Time most definitely flies!  I have been using Doug Hennig’s Project Explorer on some projects. I decided to implement it with my VFPX projects, as well as do some housekeeping on GitHub. In the process, I noticed there were several tweaks/fixes (things checked in years ago on CodePlex) that never made their way into an official release.  So, I packaged those changes up into a new release: ParallelFox 1.3.

POTENTIAL BREAKING CHANGE: This release includes and requires ParallelFox.exe version 2.0 dated March 5, 2012. If you are using a previous version, this version needs to be installed and registered. This release is otherwise backwards compatible with previous versions, and it should not require changes in your code.

NOTE: If you previously cloned/downloaded the GitHub repository, you already have the changes in this release, including the latest ParallelFox.exe.

COM Interop with .NET Core 2.0

We previously discussed that COM Interop does not function in .NET Core 1.0.  What about .NET Core 2.0?  The answer is YES… with limitations.

The first and most obvious is that COM Interop only works with Windows, not other platforms.

The second limitation is that the .NET Core implementation does not include IDispatch, which means that late binding is not supported.  Almost 10 years ago, Microsoft introduced the dynamic keyword in C# 4.0, which made late binding with COM and other platforms much easier.

dynamic excel = Activator.CreateInstance(Type.GetTypeFromProgID("Excel.Application", true));
excel.Visible = true;
Console.WriteLine("Press Enter to close Excel.");
Console.ReadLine();
excel.Quit();

The above code will function in .NET Framework, but in .NET Core 2.0, an exception occurs:

‘System.__ComObject’ does not contain a definition for ‘Visible’

If you look in Task Manager, you’ll see that Excel.exe has indeed started, but the object members cannot be access directly without IDispatch.  To work around this, you can use interop techniques that pre-date the dynamic keyword.

Interop assemblies are wrappers that enable .NET Core to interact with COM objects using early binding.  Microsoft provides interop assemblies for Office automation on NuGet and elsewhere.  Once the assemblies are installed, this code will work:

using Excel = Microsoft.Office.Interop.Excel;
...
var excel = new Excel.Application();
excel.Visible = true;
Console.WriteLine("Press Enter to close Excel.");
Console.ReadLine();
excel.Quit();

Aside: For web applications, Office automation is not recommended.  Check out the Open XML SDK.

What about your own COM objects? .NET Core projects do not provide a means to reference them directly.  However, you can create a .NET Framework 4.x project and add a reference to the COM object.  This will create an Interop.MyCOMObject.dll assembly in the obj/Debug folder, which you can then reference directly in the .NET Core project.

A COM object may return other objects that are not part of the type library, and early binding is not an option. This happens often in my Visual FoxPro interop code. You can use reflection to access the object members.

object excel = Activator.CreateInstance(Type.GetTypeFromProgID("Excel.Application", true));
excel.GetType().InvokeMember("Visible",BindingFlags.SetProperty, Type.DefaultBinder, excel, new object[] { true });
Console.WriteLine("Press Enter to close Excel.");
Console.ReadLine();
excel.GetType().InvokeMember("Quit", BindingFlags.InvokeMethod, null, excel, null);

The dynamic keyword makes for more natural code, but you can make reflection less cumbersome than above with your own wrapper methods.

For the adventurous, the Powershell team has created their own implementation of IDispatch. I don’t know how reusable this implementation is, but it may be worth a look.

If you’re using in-process (DLL) COM servers, be aware of 32-bit vs 64-bit issues. For web  applications, take a look a Rick Strahl’s post on STA components. I don’t know if these techniques are available in .NET Core.  In my experience, these issues do not apply with out-of-process (EXE) COM servers, but your mileage may vary.

Lastly, keep in mind that ASP.NET Core 2.0 continues to run on .NET Framework 4.x, in addition to .NET Core.  If you’re already restricted to Windows, there aren’t many reasons to prefer .NET Core over the full framework (yet), so it remains the best option for COM Interop.  That said, it’s good to know these possibilities exist with .NET Core.

Microsoft has been choosy about what they bring over to .NET Core.  Over time, they have been finding their way towards more parity with .NET Framework. It was recently announced that WinForms/WPF will be coming to .NET Core 3.0. They may find that a lot of existing code relies on late binding.  I would not be surprised if IDispatch makes a comeback.

Welcome to JoelLeach.net!

Nearly a decade ago, I started this blog on the Foxite.com Community Weblog, a free service made available to the FoxPro community by Eric den Doop.  I wanted more control on the admin side — especially for dealing with spam – so I have moved the blog to my own site: joelleach.net.

All posts/comments have been retained, and links to the old site should automatically redirect to the new site.  Please update your RSS readers to point to the new feed.

Special thanks to Eric for making this service available to the community and for hosting my blog all these years.

Setting Subclass Properties in TypeScript

TypeScript brings full class-based inheritance to JavaScript projects.  This works very well, but you may run into some unexpected behavior when setting properties in a subclass and using those properties in the parent constructor.

Here is a simple example that demonstrates the problem:

  • MyBaseClass is defined as an abstract class. Like other OOP languages, this means that the class cannot be instantiated directly.
  • MySubClass is a concrete subclass of MyBaseClass that can be instantiated.
  • New in TypeScript 2.0 is the ability to define properties as abstract, which I have done with string1 and string2.  These properties must be set in the subclass, or the transpiler will generate an error.
  • The parent class constructor sets the string3 property based on the values of string1 and string2 set in the subclass.  Imagine that string3 is a property that will be used by other methods in the base class (not shown in the example code), so it is a valid design choice to set that property in the constructor.
  • Finally, the last two lines of code instantiate the class and display string3.
// Abstract base class
abstract class MyBaseClass {

    // Abstract properties to be set in subclass
    protected abstract string1: string;
    protected abstract string2: string;

    public string3: string;

    constructor() {
        // Set string3 so it is available for rest of class
        this.string3 = this.buildString3();
    }

    protected buildString3(): string {
        return this.string1 + " " + this.string2;
    }
}

// Concrete subclass
class MySubClass extends MyBaseClass {

    // Abstract properties must be set or
    //  transpiler error will occur
    protected string1 = "Hello";
    protected string2 = "World!";
}

// Create object and display string3
var myObject = new MySubClass();
alert(myObject.string3);



Of course, I expected this code to display “Hello World!”, but in fact it displays “undefined undefined”.  Why is that?  A look at the transpiled Javascript of the subclass constructor will give us a clue.

    function MySubClass() {
        _super.apply(this, arguments);
        // Abstract properties must be set or
        //  transpiler error will occur
        this.string1 = "Hello";
        this.string2 = "World!";
    }



As you can see, the subclass properties aren’t set until AFTER the base constructor is called. Ryan Cavanaugh from Microsoft explains:

This is the intended behavior.

The order of initialization is:

1. The base class initialized properties are initialized

2. The base class constructor runs

3. The derived class initialized properties are initialized

4. The derived class constructor runs

Follow the link for more details on the reasons, but it comes down to the fact that property initialization is inextricably intertwined with the constructor. Alternative approaches have been suggested, but besides breaking existing code, the order above is likely to become part of the EcmaScript (JavaScript) standard.

As an OOP veteran of other languages, I find this behavior unfortunate. By defining a class as abstract, you are in effect saying it is “incomplete“, and it will be completed by its concrete subclasses. These technical restrictions on property initialization and constructors get in the way, but there are things we can do to work around the problem.

Constructor Parameters

Rather than setting properties in the subclass, you can pass values to the base class constructor.

// Abstract base class
abstract class MyBaseClass {

    // Changed abstract properties to private properties
    //  available in base class only
    private string1: string;
    private string2: string;

    public string3: string;

    constructor(string1: string, string2: string) {
        // Set private properties in constructor
        this.string1 = string1;
        this.string2 = string2;
        // Set string3 so it is available for rest of class
        this.string3 = this.buildString3();
    }

    protected buildString3(): string {
        return this.string1 + " " + this.string2;
    }
}

// Concrete subclass
class MySubClass extends MyBaseClass {

    constructor() {
        // Pass values to base constructor
        var string1 = "Hello";
        var string2 = "World!";
        super(string1, string2);
    }
}

// Create object and display string3
var myObject = new MySubClass();
alert(myObject.string3);



This works, but stylistically, I don’t like it for an inheritance-based approach.  I’d rather have the ability to simply set properties in the subclass, but call it personal preference.  There is nothing wrong with this solution.

Constructor Hook Method

Here, I’ve added an initialize() hook method to the constructor that runs before the buildString3() method. This gives the subclass an opportunity to set properties the base class needs at the appropriate time.  I’ve declared the initalize() method as abstract, so that it must be implemented in the subclass.

// Abstract base class
abstract class MyBaseClass {

    // Properties to be set in subclass
    protected string1: string;
    protected string2: string;

    public string3: string;

    constructor() {
        // Call subclass initialize() before string3 is set
        this.initialize();
        // Set string3 so it is available for rest of class
        this.string3 = this.buildString3();
    }

    abstract initialize(): void;

    protected buildString3(): string {
        return this.string1 + " " + this.string2;
    }
}

// Concrete subclass
class MySubClass extends MyBaseClass {

    // Set properties
    initialize(): void {
        this.string1 = "Hello";
        this.string2 = "World!";
    }
}

// Create object and display string3
var myObject = new MySubClass();
alert(myObject.string3);



This also works, but it leaves much to be desired.  Even though I have declared the initialize() method as abstract, nothing forces the string1 and string2 properties to be set.  Notice that I had to remove the abstract keyword from those properties for this to transpile without error. In general, I like the idea of adding hook methods for subclasses to use, but they should be optional.  The base class should not depend on them, nor should it be ambiguous about which properties need to be set.

Getters/Setters

As you may have gathered from the above, methods do not suffer from the same constructor timing issues as properties.  The base class constructor called into the subclass initialize() method, and it functioned as expected.  Likewise, using getter/setter syntax for properties is an option:

// Abstract base class
abstract class MyBaseClass {

    // Abstract properties to be set in subclass
    // Use getter syntax
    protected abstract get string1(): string;
    protected abstract get string2(): string;

    public string3: string;

    constructor() {
        // Set string3 so it is available for rest of class
        this.string3 = this.buildString3();
    }

    protected buildString3(): string {
        return this.string1 + " " + this.string2;
    }
}

// Concrete subclass
class MySubClass extends MyBaseClass {

    // Abstract properties must be set or
    //  transpiler error will occur
    // Getter syntax must be used in subclass as well
    protected get string1() { return "Hello"; }
    protected get string2() { return "World!"; }
}

// Create object and display string3
var myObject = new MySubClass();
alert(myObject.string3);



This is closer to the original vision.  Having to use getter syntax is a little wordy for my taste, when all you want to do is return a simple value.  You may not mind if you are used to this from other languages.

Move the Code

Finally, my favorite solution is to move the code out of the constructor, which is where the timing issue is.  I moved the code into the string3 property with getter syntax.  It won’t run until the property is accessed after the object has been constructed, so the timing issue is avoided.  I also added a private _string3 property for improved performance, but of course, that is optional.

// Abstract base class
abstract class MyBaseClass {

    // Abstract properties to be set in subclass
    protected abstract string1: string;
    protected abstract string2: string;

    // Private backing property (optional)
    private _string3: string;
    // Public property using getter syntax
    public get string3(): string {
        // Set private backing property if not already set
        if (!this._string3) {
            this._string3 = this.buildString3();
        }
        return this._string3;
    }

    protected buildString3(): string {
        return this.string1 + " " + this.string2;
    }
}

// Concrete subclass
class MySubClass extends MyBaseClass {

    // Abstract properties must be set or
    //  transpiler error will occur
    protected string1 = "Hello";
    protected string2 = "World!";
}

// Create object and display string3
var myObject = new MySubClass();
alert(myObject.string3);



This solution is the closest the original code.  I also like the idea of doing more in the base class, so you can do less in subclasses.

Your mileage may vary depending on your specific scenario, so choose the workaround that works best for you.

References

COM Interop with .NET Core

Logo_DotNet

UPDATE: COM Interop with .NET Core 2.0

The short story is that COM interop does not function in .NET Core 1.0. .NET Core is Microsoft’s open-source, cross-platform implementation of the core libraries in the .NET Framework.  With its cross-platform focus, the exclusion of COM interop is intentional.

ASP.NET Core is Microsoft’s open-source web framework that sits on top of the base .NET framework.  If you require COM interop and want to take advantage of new features in ASP.NET Core 1.0, you are in luck. Scott Hanselman reminds us that ASP.NET Core runs not only on .NET Core, but also on the full .NET Framework 4.6.

Here is some typical code for instantiating a COM object in C#:

dynamic myObject = Activator.CreateInstance(Type.GetTypeFromProgID("My.COMObject", true));

If you try to compile this code with .NET Core 1.0, it simply won’t work because Type.GetTypeFromProgID() is not available in the API.

That describes the current situation, but what about the future?  A while back, there was actually talk about bringing pieces of COM to Mac and Linux.  I think those plans have been scrapped or would only have limited use.

.NET Standard is an effort to bring a minimum common API set to all .NET platforms, present (Full Framework 4.6, .NET Core, Xamarin, Mono) and future.  .NET Standard 2.0 will be implemented in .NET Core 1.1, and it brings in a lot of missing APIs from the full framework. (UPDATE: .NET Core 1.1 has been released since this was written. It includes many new APIs, but not full support for .NET Standard 2.0. That will show up in a future release of .NET Core.)   It should make porting existing code to .NET Core much easier.  One of the APIs slated for 2.0 (as of this writing) is Type.GetTypeFromProgID().  That means that COM interop will work on .NET Core 1.1, right? Wrong. Calling this method will throw a “Not Implemented” or “Platform Not Supported” error.  As I was told by a .NET Foundation member:

There is often incorrect assumption made that “included in .NET Standard” == “works in .NET Core”. There are going to be some APIs that will throw PlaformNotSupportedException on .NET Core, also this set be different between Windows and Unix.

That’s a bit counter-intuitive to me. First of all, it seems like .NET Core should be the “reference implementation” of .NET Standard.  Beyond that, the availability of APIs on unsupported platforms may lead a developer to believe an API is fully functional when it is not. To solve that issue, tooling is coming that will identify APIs that are not supported on certain platforms/runtimes (hopefully before a developer has gone through a porting effort). Also, keep in mind that a least-common-denominator approach has already been tried with Portable Class Libraries, and the .NET team is going for something better. The .NET Standard team is currently accepting feedback on GitHub, so feel free to post your thoughts and questions.

Looking beyond .NET Standard 2.0 and .NET Core 1.1, several COM/native interop pieces have already been segregated for a possible future extension. Also, the source code for the underlying functionality is readily available.  I think it is only a matter of time before COM interop will be available for use with .NET Core.

References:

Report Metadata Error

A few of our clients were getting an obscure error when running reports.  I couldn’t find any information on the error online, so I thought I would post a potential workaround here to help the next person that runs into it.

While the report is running and being prepared for preview, a dialog pops up prompting the user to find a table/DBF. When the user presses Cancel, the dialog may or may not pop up again multiple times. Eventually, the user receives this error:

File ‘m_4nl0nroh6.dbf’ does not exist.
The metadata for some report definition rows could not be loaded.
Some dynamic report features may be missing, or a report could not conclude successfully.

The error occurs in frxcursor.UnpackFrxMemberData() while attempting to ALTER TABLE on a cursor that was created only a few lines earlier. For some reason, the underlying DBF is missing, but I can’t explain why.

What I did find is that some of our reports contained generic MemberData in the STYLE field of the FRX that was not being used. Once removed, the code producing the error will not need to run. I suspect the data inadvertently got in there in the first place using the Report Designer. If you go to Field Properties->Other and click on the Run-time extensions->Edit Settings button, it will automatically add code to the STYLE field, which will be saved if you press OK.

NOTE: There are legitimate uses of MemberData in the STYLE field, such as rotated labels. In those cases, the STYLE field needs to remain populated, so be sure before deleting the data.

SCCTextX for Data

Over the years, there have been debates about whether it is best to use source control integrated with the VFP Project Manager or to keep it separate.  I’ve always preferred to have the integrated experience.  Regardless of which side you fall on, it is very useful to have textual representations of VFP’s binary source files (SCX, VCX, etc.).  These text files enable diffs, so a developer can compare different versions of a source file and see what changes were made.  VFP includes SCCText.prg in the box, which has improved over time, but leaves a lot to be desired.  The SCCTextX project on VFPX is a major improvement and makes the resulting text files much more usable.

However, one thing I’ve always wanted was the ability to generate text files for DBCs and DBFs that we include in our project and source control.  The DBCs contain valuable information about the data structures, as well as local/remote view definitions.  The DBFs are primarily metadata for things like Stonefield Database Toolkit and the framework we use, Visual ProMatrix.  Before I checked in my latest changes to these files, I decided to crack open SCCTextX.prg and take a look at what could be done.  Lo and behold! There is already code to deal with DBCs and the beginnings of code for DBFs, which by default had been disabled.  I thought to myself, “I could have something working within a couple of hours”, so I dug in. Three days later… I finally had a solution, but with caveats.

There was a reason the code for DBCs was disabled.  The text file it produced was useless for diffs.  After some trial, error, and experimentation, I ended up with modified versions of SCCTextX.prg and FoxPro’s GenDBC.prg .  SCCTextX_Data.prg now calls GenDBC_SCCTextX.prg to generate a text file for DBCs.  It expects GenDBC_SCCTextX.prg to be in the same directory as SCCTextX_Data.prg.  I made two modifications to the GenDBC program.  The first was to sort the entries, so they are created in a consistent order.  The second was to parse CREATE SQL VIEW commands into multiple lines, which otherwise appear in GenDBC on one line, making it very difficult to see what has changed.  I’ll tell you up front that the parsing is not very good, and definitely not as good as I have seen in other VFP products/projects, but I needed something simple and lightweight, and I find it good enough for diff purposes.  Also, GenDBC is a little slow compared to other text file generation, but it wasn’t a showstopper for me.  NOTE: GenDBC_SCCTextX.prg is only intended for source control diff purposes, and I do not recommend it as a replacement of the standard GenDBC.prg for creating databases.

Aside: If you look in SCCTextX.prg, you may notice the developers tried to change the extension for DBC text files from “DBA” to “DCA”.  I agree with this change.  Unfortunately, the VFP Project Manager forces and expects the DBA extension.  If some aspiring developer were to create a fully functional replacement for the Project Manager on VFPX (hint, hint), this (and other limitations with source control integration) could be overcome.  But as it stands, we have no control over it.

That takes care of DBCs, how about DBFs?  Well, it turns out that the code included in SCCTextX.prg for DBCs is actually pretty good for DBFs.  So, easy right? Wrong.  The first problem has to do with the Project Manager integration.  VFP doesn’t even call SCCTextX for files in the Free Tables section.  That explains why we only have the “beginnings” of DBF support.  However, we can trick VFP into calling SCCTextX by putting the DBF into the Databases section of the project.  There are three ways to do this:

  1. Add the DBF manually in the Databases section.  VFP will complain, but the file will still be there.
  2. Hack the PJX (USE MyProject.PJX) and change the type from “D” to “d” on the applicable files.
  3. If the project is open: _VFP.ActiveProject.Files(“MyTable.dbf”).Type = “d”

Once the DBF is in this section, VFP will call SCCTextX and otherwise integrate properly with source control.  SCCTextX_Data.prg is smart enough not to run GenDBC for files that don’t have a “DBC” extension.  The text file extension for both DBCs and DBFs will be “DBA”, so you can’t have a table and database of the same name, but that wasn’t a problem for me.

So far, so good, but there are other issues with DBFs.  You might want to exclude certain fields like ID fields or timestamps that change often and clutter the diffs.  Or you might want set the order for the table to get consistent results.  For this purpose, SCCTextX_Data.prg will call SCCTextX_Custom.prg if it exists in the same directory, giving you an opportunity to specify these settings.  See SCCTextX_Custom – Example.prg in the download.

So now we’ve got text files for DBCs and DBFs, integrated with the Project Manager.  Time for a quick build and… FAIL.  Ugh! VFP doesn’t like the DBFs in the Databases section.  Nothing a little project hook (included in the download) can’t fix though.  It moves all non-DBCs to the Free Tables section before the build and puts them back afterwards.

With all of these caveats, I think it is obvious why I won’t be submitting my changes to the SCCTextX project manager at VFPX.  That said, I’ll tell you it is VERY nice to finally be able to run diffs on these files.  Definitely worth the caveats and overall effort for me.  If you want to try it yourself, feel free to download SccTextX_data.zip.

The End of the Road for Windows XP?

You may or may not have noticed that most new products coming out of Microsoft these days do not include support for Windows XP or Windows Server 2003.  Here is a sampling:

On a related noted, Windows 8 no longer includes “Windows XP Mode”.  That’s a curious choice by Microsoft as it could prevent businesses from upgrading.  You can get similar functionality using Hyper-V, but it’s not as integrated, nor does it include the license for XP.  NOTE: If you plan to upgrade a Windows 7 machine that contains XP Mode VM’s to Windows 8, you may need to take action BEFORE upgrading.

On the surface, this seems reasonable.  After all, Windows XP was released 11 years ago, mainstream support ended in 2009 (extended support ends in 2014), and there have been three new Windows releases: Vista, Windows 7, and now Windows 8.  Going back to 2001, there was a little bit of an uproar when Microsoft ended support for Windows 95.  I remember thinking it was no big deal, because anyone with smarts long ago upgraded Windows 98/SE, or better yet, Windows 2000.  Besides, it had been SIX YEARS! Did anyone expect Microsoft to support it forever?

In spite of being supported far longer than Windows 95, the sun-setting of Windows XP seems like it will have far greater impact.  Maybe it’s that I’m older.  Maybe it’s the fact that 40% of computers still run Windows XP (although Windows 7 finally surpassed XP earlier this year).  Maybe it’s that even though XP is 11 years old, Vista wasn’t released until 5 years later, and subsequently avoided by the majority until Windows 7 was released in 2009.  If you’ve got a PC more than 3 years old, there’s a good chance it is running XP.

That 40% is reflected in our client base, if not higher.  Fortunately, Visual FoxPro runs great on Windows XP.  However, we are starting to use SQL Server and .NET in addition to FoxPro.  I have to choose between forcing clients to upgrade or using last year’s technology (not exactly cutting edge).  I know you eventually have to move on, but it feels like Microsoft is forcing the issue a little too soon.  Perhaps Windows XP usage will drop off sharply within the next year, but I wouldn’t bet on it.

Why Microsoft Cancelled Visual FoxPro

For a while now, I have debated whether or not to post this entry.  About six months ago, I wrote most of this article, then decided not to post it.  So yeah, I’m wishy-washy on this one.  Since then, Microsoft has put a lot of emphasis on HTML5 and introduced Windows 8 and the Metro UI, leaving a lot of existing MS developers wondering about the future of their previous technology choices.  With that in mind, I think it’s good to look at Microsoft’s treatment of VFP and how their decision processes work in regard to development tools.

Can you believe it has been over four years since Microsoft posted A Message to the Community and announced that Microsoft would cease development on Visual FoxPro?  It has been over three years since Microsoft released VFP9 SP2 and Sedna, and over six years since VFP 9.0 was released!  While I was saddened that Microsoft chose to cancel VFP, I appreciated the sensitivity the Fox Team, particularly YAG, showed to the Fox community.  However, at the time, I wished Microsoft would have been more transparent and given a more thorough explanation of their reasons for making that decision.  YAG may have been constrained in what he could/should say in his position, and I imagine there was some disagreement with the decision within the Fox Team, but those are just guesses.  Regardless, we didn’t get an official statement from Microsoft, other than it was happening, and the Fox community was left to piece together the reasons.  That led to comments like “writing on the wall”, “head in the sand” and conjecture on lack of sales vs. lack of marketing, etc.  Ultimately, it comes down to the fact that VFP was not a “strategic product” for Microsoft, but why was that and what does it mean?  Answers lead to more questions, but I think that is worth exploring.

Note that this blog entry is just more conjecture/opinion.  I don’t have any more facts than you do.  I am just putting all the pieces I have on the table and building a picture.  Over the past couple of years, I have debated whether or not to write this, because it is a negative subject and obvious flame-bait.  But I think enough time has passed now and it could be a good thing.  To move forward, you have to let go of the past, and this has helped me do that.  I still use VFP as my primary tool, but this has helped me “get over” Microsoft’s decision.  It may also be helpful in deciding where you want to go in the future.  Now, I am in no way defending Microsoft or saying I agree with their decision.  I am just trying to understand why they would make a business decision to discontinue FoxPro.  Statements here may be “obvious” or “old news”, but I think it is helpful to pull it all together.

“Not a Strategic Product”

Enough disclaimers, let’s get to the subject at hand.  Microsoft has stated for some time that FoxPro was not a strategic product for them.  What does that mean?  To my mind, a strategic product is one that Microsoft would invest in heavily and recommend as the primary path for their customers.  MS would build upon the technology and form an entire “strategy” around it.  VB was strategic.  COM was strategic. .NET is strategic.  Fox was not.  Why not?  To answer that, I think you have to look at why Microsoft bought Fox Software in the first place.

Why Buy Fox?

So, why did Microsoft buy Fox Software.  I will quote an article Jordan Powell wrote in FoxTalk when Access 1.0 and FoxPro 2.5 were about to ship:

Microsoft was working on its Access DBMS which uses a modern variant of the BASIC language. It had to have been embarrassing for Microsoft to have such a glaring hole in its product lineup. They had no DBMS, and their partnership with Ashton-Tate failed to get Microsoft SQL Server off the ground. Some of the marketing types at MS realized that FoxPro was the best version of X-Base out there, and had been trying to talk Bill Gates into doing something about it. They knew that the X-Base language commanded a huge segment of the market and that a product which used the X-Base language would get them into the DBMS market in a big way. They had the marketing resources to put behind FoxPro, and Fox had some interesting and useful technology — not to mention some very talented people, the kind Microsoft likes.

More recently, Ken Levy wrote the following in his blog:

The purchase of Fox Software for $173 million in 1992 was very strategic for Microsoft, and was the biggest corporate purchase Microsoft had ever made up until that time. Borland had purchased Aston-Tate’s which included dBase III and IV, and had Paradox. And growing in popularity at the time was PowerBuilder as the king of client/server tools, with Sybase releasing PowerBuilder 12 last year ironically based on the free Visual Studio Shell runtime. Microsoft needed three things from the Fox Software deal – the Fox developer team, the Fox technology, and the customer market share of FoxPro/FoxBase. Microsoft was just starting work on Access and it was more targeting power users, but there was still some overlap. Visual Basic was still in its early days.

Basically, Microsoft wanted a stronger presence in the database market and they were in severe need of database products, people, and technology.  Fox Software was a perfect fit for them.  To give you a little more context, in 1992 the xBase market was still booming, Access (Cirrus) was still in development, Visual Basic 1.0 had been released and VB 2.0 was in development, and the first release of SQL Server for Windows was not until 1993.

I think if you asked anyone “in the know” at Microsoft, they would tell you that the Fox acquisition was a resounding success (unlike other much more expensive acquisitions that Microsoft has recently dumped).  They got a solid product, key technology that made its way into several other products, and valuable people that went on to take major roles in the company.  Why then did FoxPro not share that level of success?  I do not believe Microsoft had malicious plans to kill FoxPro from the beginning, but the landscape had changed, as it tends to do in technology.  The xBase market declined.

xBase Market Decline

FoxPro was first and foremost a competitor in the xBase market.  As that market declined, so did the value of FoxPro as a strategic product to Microsoft.  What led to the decline of a technology that had been so popular in the 80’s and early 90’s?  Technology trends are constantly changing, but here are few key things that in my opinion diminished the xBase market:

dBASE IV: dBASE IV was a buggy disaster, and it was two years before they released version 1.1.  Borland bought Ashton-Tate, but could not undo the damage.  dBASE for Windows was not released until 1994.  This was good for FoxPro, which became the biggest fish in the xBase pond, but the pond itself began to shrink.

Lawsuit: Ashton-Tate sued Fox Software for cloning dBASE.  The suit was dropped when Borland bought Ashton-Tate, but it could not have inspired confidence in the xBase market.

Client-Server: By the early 90’s, client-server technology picked up in popularity and developers were beginning to flock towards database servers and client-server development tools like PowerBuilder and VB.  At the same time, Microsoft was trying to enter the server market with Windows NT and SQL Server, so I’m sure there was strong emphasis on this style of development from them.  I believe there was talk of a “FoxServer” product at Fox Software, but it never saw the light of day before the Microsoft acquisition.

Those are reasons that the xBase market declined, but about now you’re thinking that VFP is so much more than an xBase tool.  I couldn’t agree more.  VFP can go toe-to-toe with VB, PowerBuilder, Delphi, .NET, and others.  If FoxPro was supposed to “go quietly into the night”, someone forgot to tell the VFP 3.0 team, because they transformed the Fox into a full-fledged OOP development platform ready for the 32-bit world and beyond.  So, why wasn’t the emphasis there from Microsoft?

An important point to make about Microsoft is that they are a follower of development trends, not a leader.  With a few exceptions (the VB GUI designer comes to mind), Microsoft has not been the one to create a development trend.  “Embrace and extend” was their motto, and they have done well with that.  Windows was Microsoft’s answer to the Mac.  .NET is Microsoft chasing Java into the enterprise.  They follow current trends and they do so mercilessly.  Even now, Microsoft is emphasizing HTML5, leaving Silverlight developers thinking “Wait, I thought we were on the cutting edge?”  It would be out of character for Microsoft to promote and strategize around a product built for a market that was trending downwards.  It’s nothing personal against the Fox, it’s just not in their DNA.

FoxPro Market Decline

Even with the xBase decline, if FoxPro revenue had continued upward, I wouldn’t be writing this article.  Sales declined, and there are several reasons for that:

Power Users: Going all the way back to dBASE you could question whether it was a platform for power users with development capabilities or a platform for developers that power users could use.  It was both.  Visual FoxPro put it squarely in the developer category, and Access took over as the preferred database for power users.  The result: much fewer licenses sold.

VB, SQL Server, .NET: VFP faced a lot of competition from other products within Microsoft.  With the emphasis always on the latest trends, many developers felt compelled to move to other technologies.

Visual FoxPro: That’s right, VFP itself.  While VFP 3.0 was a massive improvement in development capabilities (and most of us are happy with that decision), it was also a big leap from FoxPro 2.x in terms of learning curve.  It took some developers quite a while to make the jump, and some never did.

Not Invented Here Syndrome:  Microsoft took a great product and made it even better, which makes their treatment of FoxPro all the more frustrating.  But Fox was still the stepchild and it was never going to supersede other products developed internally.  By the time Microsoft purchased Fox, they had already made significant investments in VB, Access, and SQL Server.  Those would be Microsoft’s strategic products while Fox would continue serving the declining xBase market and otherwise fit between the lines.

Why 2007?

People had been foretelling the death of FoxPro since Microsoft bought it in 1992.  What made 2007 the year when Microsoft finally decided to cancel it?  Had sales declined to the point that Microsoft could no longer justify Fox development?  Did they want to use the Fox Team in other parts of Microsoft?  Did big customers move to something else?  Were the people that cared gone or no longer in a position to do anything about it?  Your guess is as good as mine.  We will never know.

There are a couple of ways to look at this: 1) Microsoft always wanted to cancel Fox and they finally got their way, or 2) in spite of Fox not being a strategic product, Microsoft continue to create new versions for Fox developers.  I tend to think of it as the latter.  While there was always a question of Microsoft’s commitment to FoxPro, by the release of VFP 5, it had become clear that it would not be a strategic product.  Per Ken Levy’s blog:

In the initial years after the Fox Software merger, Microsoft put a huge effort and lots of resources into creating VFP 3.0. There were about 50 people on the Fox team with a big marketing budget. In the following years, both Access and VB grew in market share and also competed in ways with the VFP market (and messaging), and by the time VFP 5.0 was released, many upper managers wanted Microsoft to just end VFP there. In fact, they did for a short time. I was there, in a meeting with 40 people, and the formal announcement was made to the Fox team that VFP was dead. It was very early 1996, and that meeting lead to the Gartner Group releasing their report that VFP was dead, which had a major impact on future VFP sales.

Most of Microsoft’s competitors would have ended it right there and VFP 5 would have been the last version.  So, the real question isn’t “Why 2007?”, it’s “Why not 1996?”.  Ken Levy continues:

But the Fox team members along with the community helped convince the developer tools management to keep VFP evolving while decreasing the resources. In fact, the primary reason VFP lasted another decade with 4 more versions released was more about Windows sales than VFP sales. There are many Windows machines running VFP apps. When Steve Ballmer jumps around like monkey boy and yells “developers, developers, developers”, he’s thinking about selling Windows and Office more than sales of developer tools.

If VFP 5 had been the last version, then I may have never had the joy of working with Visual FoxPro, because I really didn’t make the jump from FoxPro 2.x until version 6.0.  In fact, I’m not sure where I’d be today, as I took my current job back in 2000 to upgrade a Fox 2.x app to VFP.  So, I’m definitely thankful Microsoft saw fit to continue development.

That said, Microsoft’s handling of VFP support since the announcement has been appalling.  VFP 9 SP2 introduced several bugs.  After months of begging, we were able to get them to fix one key bug, but others remain that will never be fixed and must be worked around.  Microsoft claims that VFP is supported until 2015, but I’m sorry, that’s not support.  To be clear, I’m not blaming the Fox Team for this.  I’m blaming Microsoft for the fact that there was no Fox Team and management was unwilling to provide resources to fix these problems.  Real support ended when the Fox Team was disbanded and assigned to other projects.

So, what now?  That’s the big question Fox developers are asking themselves or have already answered.  I don’t know about you, but I continue to be extremely busy with Visual FoxPro as my primary development tool.  I also keep tabs on new technologies as they are introduced with an eye towards how they could benefit me.  Maybe that will be the subject of a future post.
